Leírás és Paraméterek
-
Unique Feature
Superb Productivity
- PCIe Gen5 (Graphics, M.2)
- Blazing M.2 Gen5 Fan Heatsink
- Dual Channel DDR5
- USB4 Type-C Ports (40 Gb/s)
Rock-Solid Durability
- Ultra Low-Loss PCB
- 24+2+1 Power Phase, 105A SPS with Enlarged Heatsink Armor
- Flexible Integrated I/O Shield
- Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors)
Ultrafast Gaming
- Killer 2.5G LAN, Killer 802.11ax Wi-Fi 6E Module
- Killer DoubleShot™ Pro
- ASRock Lightning Gaming Ports
EZ Update
- BIOS Flashback Button
- ASRock Auto Driver Installer -
CPU
- Supports AMD Socket AM5 Ryzen™ 8000 and 7000 Series Processors*
- Supports ASRock Hyper BCLK Engine
*The availability of expansion slots may vary by CPU. Please refer to PCIe/M.2 Bandwidth Table for details.
-
Chipset
- AMD X670
-
Memory
- Dual Channel DDR5 Memory Technology
- 4 x DDR5 DIMM Slots
- Supports DDR5 ECC/non-ECC, un-buffered memory up to 7800+(OC)*
- Max. capacity of system memory: 192GB
- Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules
*Please refer to Memory Support List for more information.
-
BIOS
- 256Mb AMI UEFI Legal BIOS with GUI support
-
Graphics
Integrated AMD RDNA™ graphics (Actual support may vary by CPU)
- 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz
- 2 x USB4, support HDCP 2.3 and max. resolution up to 8K 60Hz*
*Only the CPU's embedded graphics can be displayed through USB4 ports. If you want to display to a Type-C monitor, please use AM5 Ryzen™ 7000 processors with embedded graphics.
-
Audio
- 5.1 CH HD Audio with Content Protection (Realtek ALC4082 Audio Codec)
- WIMA Audio Capacitors (For Front Outputs)
- ESS SABRE9218 DAC for Front Panel Audio (130dB SNR)
- Individual PCB Layers for R/L Audio Channel
- Impedance Sensing on Rear Out port
- Nahimic Audio -
LAN
- 2.5 Gigabit LAN 10/100/1000/2500 Mb/s
- Killer E3100G
- Supports Killer LAN Software
- Supports Killer DoubleShot™ Pro
Audio | 7.1 HD |
Chipset gyártó | AMD |
D-Sub | Nincs |
Display Port | Nincs |
DVI | Nincs |
Foglalat típusa | AM5 |
Form Factor | E-ATX |
Grafikus foglalat | 2 x PCI-Ex16x |
Gyártó | ASROCK |
HDMI | Van |
Kivitel | dobozos |
LAN1 | 100/1000/2500 Mb/s |
M.2 foglalat | Van |
Max memória | 192 |
Memória foglalatok száma | 4 |
Memória órajel | 7200 |
Memória típus | DDR5 |
Párhuzamos port | Nincs |
Quad Channel | Nincs |
Raid | Igen |
SATA III | 8 |
Soros port | Nincs |
Thunderbolt | Nincs |
USB 2.0 | 8 |
USB 3.1 | 13 |
VGA integrált | Nincs |
Wireless | Van |
