Leírás és Paraméterek
Model Name
4G-AX56
Network Standard
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
IPv4
IPv6
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
IPv4
IPv6
Product Segment
AX1800 ultimate AX performance
Data Rate
802.11a : up to 54 Mbps
802.11b : up to 11 Mbps
802.11g : up to 54 Mbps
WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps
WiFi 6 (802.11ax) (5GHz) : up to 1201 Mbps
802.11b : up to 11 Mbps
802.11g : up to 54 Mbps
WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps
WiFi 6 (802.11ax) (5GHz) : up to 1201 Mbps
Connectivity Technology
LTE: Downlink 300 Mbps / Uplink 50 Mbps
HSPA+: Downlink 42 Mbps / Uplink 11 Mbps
4G FDD-LTE: 2100 /1800 /850 /2600 /900 /800 /700
4G TDD-LTE: 2300 /2600 /2500
3G UMTS: 2100 /1800 /850 /900
HSPA+: Downlink 42 Mbps / Uplink 11 Mbps
4G FDD-LTE: 2100 /1800 /850 /2600 /900 /800 /700
4G TDD-LTE: 2300 /2600 /2500
3G UMTS: 2100 /1800 /850 /900
Antenna
WiFi: 2 x external fixed antenna
LTE: 1 x external fixed antenna, 1 x internal antenna
LTE: 1 x external fixed antenna, 1 x internal antenna
Memory
128 MB Flash
512 MB RAM
512 MB RAM
Operating Frequency
2.4 GHz / 5 GHz
Ports
1 x Gigabit WAN port, 4 x Gigabit LAN ports, 1 x Nano SIM tray slot
Button
Power, Reset, WPS
LED Indicator
Power x 1
WiFi x 2
WAN x 1
Mobile WAN connection x 1
Mobile WAN signal x 3
WiFi x 2
WAN x 1
Mobile WAN connection x 1
Mobile WAN signal x 3
Package content
4G-AX56
Quick Start Guide
Warranty Card
RJ45 Cable
Power Adapter
Quick Start Guide
Warranty Card
RJ45 Cable
Power Adapter
Product Weight (g)
753
AiMesh
AiMesh : No
Primary AiMesh router : No
AiMesh node : No
Primary AiMesh router : No
AiMesh node : No
Router APP
ASUS Router APP : Yes
Game
Game Boost/acceleration : No
WTFast : No
WTFast : No
Alexa
Support Alexa skill : Yes
IFTTT
Support IFTTT : No
AiProtection
AiProtection : AiProtection Classic
Router Security Assessment : Yes
Malicious site blocking : Yes
Two-Way IPS : No
Infected Device Prevention and Blocking : No
Router Security Assessment : Yes
Malicious site blocking : Yes
Two-Way IPS : No
Infected Device Prevention and Blocking : No
Parental Control
Parental Control : Yes
Parental Control Customized Internet schedule : Yes
Parental Control Customized Internet schedule : Yes
Traffic Control
Adaptive QoS : No
Bandwidth Monitor : No
Bandwidth limiter : Yes
Traditional QoS : Yes
Traffic Monitor : No
Real-time traffic monitor : Yes
Wired Traffic Monitor : Yes
Traffic Analyzer : No
Website history : Yes
Bandwidth Monitor : No
Bandwidth limiter : Yes
Traditional QoS : Yes
Traffic Monitor : No
Real-time traffic monitor : Yes
Wired Traffic Monitor : Yes
Traffic Analyzer : No
Website history : Yes
Wireless
IPv6 : Yes
MU-MIMO : Yes
UTF-8 SSID : Yes
Guest Network : Yes
Guest Network Connection time limit : Yes
WPS : Yes
Wi-Fi MAC address filter : Yes
Wireless scheduler : Yes
Airtime fairness : Yes
RADIUS Server : No
Universal beamforming : Yes
Explicit beamforming : Yes
MU-MIMO : Yes
UTF-8 SSID : Yes
Guest Network : Yes
Guest Network Connection time limit : Yes
WPS : Yes
Wi-Fi MAC address filter : Yes
Wireless scheduler : Yes
Airtime fairness : Yes
RADIUS Server : No
Universal beamforming : Yes
Explicit beamforming : Yes
WAN
Internet connection Type : Mobile WAN, Ethernet WAN
Dual WAN : Yes
WAN Aggregation : No
3G/4G LTE dongle : No
Android tethering : No
Port forwarding : Yes
Port triggering : No
DMZ : Yes
DDNS : Yes
NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough, PPPoE relay
Let's Encrypt : Yes
Dual WAN : Yes
WAN Aggregation : No
3G/4G LTE dongle : No
Android tethering : No
Port forwarding : Yes
Port triggering : No
DMZ : Yes
DDNS : Yes
NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough, PPPoE relay
Let's Encrypt : Yes
LAN
DHCP Server : Yes
IGMP snooping : Yes
IPTV : Yes
LAN Link Aggregation : No
Manually assign IP address : Yes
Maximum manually assign IP address rule : 64
IGMP snooping : Yes
IPTV : Yes
LAN Link Aggregation : No
Manually assign IP address : Yes
Maximum manually assign IP address rule : 64
VPN
VPN Client L2PT : Yes
VPN Client OVPN : Yes
VPN Client PPTP : Yes
VPN Server IPSec : No
VPN Server OVPN : Yes
VPN Server PPTP : Yes
VPN Fusion : No
VPN Client OVPN : Yes
VPN Client PPTP : Yes
VPN Server IPSec : No
VPN Server OVPN : Yes
VPN Server PPTP : Yes
VPN Fusion : No
USB application
File System : No
HDD hibernation : No
Safely Remove disk : No
AiCloud : No
Download master : No
Media Server : No
AiDisk : No
Time Machine : No
Samba Server : No
FTP Server : No
Shared Folder privileges : No
HDD hibernation : No
Safely Remove disk : No
AiCloud : No
Download master : No
Media Server : No
AiDisk : No
Time Machine : No
Samba Server : No
FTP Server : No
Shared Folder privileges : No
Administration
Operating mode : Modem Router,Access Point
Operating system : Yes
Firewall : Yes
Maximum Firewall keyword filter : 64
Maximum Firewall network service filter : 32
Maximum Firewall URL filter : 64
Wake on LAN (WOL) : Yes
Configuration backup and restore : Yes
SSH : Yes
Diagnosis tools : Yes
Feedback system : Yes
System log : Yes
Operating system : Yes
Firewall : Yes
Maximum Firewall keyword filter : 64
Maximum Firewall network service filter : 32
Maximum Firewall URL filter : 64
Wake on LAN (WOL) : Yes
Configuration backup and restore : Yes
SSH : Yes
Diagnosis tools : Yes
Feedback system : Yes
System log : Yes
| Frekvencia | 2,4 GHz és 5 GHz |
| Gyártó | ASUS |
| Sebesség | AX1800 |
| Szabvány | 802.11b, 802.11g, 802.11n, 802.11ac, 802.11ax |
