Leírás és Paraméterek
|
Acoustic |
Max: 50.01 dB (fan high speed) Min: 41.2 dB (fan low speed) |
|---|---|
|
Dimensions |
440 x 470 x 44 mm (17.32 x 18.50 x 1.73 in) |
|
FAN |
2 x Smart fans |
|
Humidity |
Operating: 10% ~ 90% RH Storage: 5% ~ 90% RH |
|
Interfaces |
24 x 100M/1G/2.5G/5G/10GBASE-T 60W PoE++ ports 4 x 10/25G SFP28 ports |
|
Max. Packet Forwarding Rate |
506.92 Mpps |
|
Maximum Heat Dissipation |
3439.637 BTU/hr @790W 6081.446 BTU/hr @1440W |
|
Maximum Power Consumption |
Max: AC CRPS at 100V/60Hz PoE Off: 95.9 W PoE On: w/ dual CRPS: 1782.37 W (AC CRPS x 2) PoE On: w/ single CRPS: 1008.1 W (AC CRPS x 1) Standby: 50.18 W |
|
MTBF |
286,495.20 hours |
|
Optional Redundant Power Supply |
AC (DPS-PWR1200AC) hot-swappable redundant power supplies DC (DPS-PWR1200DC) hot-swappable redundant power supplies |
|
PoE Power Budget |
1440 W (dual power supplies) 790 W |
|
Stacking Ports |
4 |
|
Standards |
IEEE 802.3af IEEE 802.3at IEEE 802.3bt |
|
Switch Capacity |
680 Gbps |
|
Temperature |
Operating 0 to 50 °C (32 to 122 °F) Storage: -40 to 70 °C (-40 to 158 °F) |
|
USB |
1 x USB 2.0 Type A port |
|
Weight |
6.48 kg (14.29 lbs) |
| Gyártó | DLINK |
| Menedzselhető | Van |
| Menedzselhetőség | Teljes |
| Port típusa | 10Gb Réz |
| Portok száma | 28 |
| Rack-be szerelhető | Van |
| SFP port | 4 |
| Switch típus | Modular |
