Leírás és Paraméterek
| General | |
| Hardware Version | A2 |
| Interfaces | 8 x 10GBASE-T copper ports 2 x 10G SFP+ optical ports 2 x 10GBASE-T/SFP+ combo ports |
| Console Port | RJ-45 console port |
| Port Standard & Functions | IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3ab 1000BASE-T Gigabit Ethernet IEEE 802.3az compliance IEEE 802.3an 10GBASE-T 10GbE over copper IEEE 802.3ae 10GbE over fiber IEEE 802.3z 1000BASE-X Auto MDI/MDIX support for 1000/10GBASE-T |
| Network Cables for 10GBASE-T | CAT-6 (30m max) CAT-6A or CAT-7 (100m max) |
| Media Interface Exchange | Auto MDI/MDIX adjustment for all twisted-pair ports |
| Performance | |
| Switching Capacity | 240 Gbps |
| Max. Packet Forwarding Rate | 178.56 Mpps |
| Transmission Method | Store-and-forward |
| MAC Address Table | Up to 16 ,000 entries per device |
| Physical/Environmental | |
| AC Input | 100 to 240 VAC |
| Maximum Power Consumption | 90.81 watts |
| Standby Power Consumption | 42.65 watts |
| Operating Temperature | 23°F to 122°F (-5°C to 50°C) |
| Storage Temperature | -40°F to 158°F (-40°C to 70°C) |
| Operating Humidity | 0% to 95% non-condensing |
| Storage Humidity | 0% to 95% non-condensing |
| Dimensions (L x W x H) | 17.36 x 8.26 x 1.73 inches (440 x 210 x 44 mm) |
| Weight | 6.94 lbs (3.15 kg) |
| Certifications | CE FCC C-Tick VCCI BSMI CCC |
| Gyártó | DLINK |
| Menedzselhető | Van |
| Menedzselhetőség | Teljes |
| Port típusa | 1Gb Réz |
| Portok száma | 12 |
| Rack-be szerelhető | Van |
| SFP port | 12 |
| Switch típus | Fixed port |
