Leírás és Paraméterek
Specs
Features
Standards
Speed
Interface
Operating
Reliability
Physical & Environment
Emission (EMI) and Safety Certifications
- Hot Pluggable
- MSA Compliant
- RoHS Compliant
Standards
- Compliance with IEEE802.3ae, 10GBASE-LR
- Form Factor Type: SFP+
- Fibre Channel FC-PI standard: 1200-SM-LL-L
- Fiber Media support: Single-Mode
- Distance Capacity: 10Km
Speed
- 10Gbps
Interface
- Duplex LC Connector
- Single-direction
- Wavelength: 1310nm
- Output (TX) Optical Power
- MAX.: +0.5 dBm
- MIN.: -8.5 dBm
- Input (RX) Optical Power
- MAX.: +0.5dBm
- MIN.: -12.6 dBm
- Sensitivity: -12.6 dBm
- Cable Type: single-mode 9/125um fiber
Operating
- Power: 3.3V
- Max Input Current @3.3V: 300mA
- Power Budget
- MIN: 4.1dB
- MAX: 13.1dB
- Heat Generated 3.6KJ/H
Reliability
- MTBF (Hours) 4,650,000
Physical & Environment
- Operation Temperature: 0°~70°C
- Storage Temperature: -40°~85°C
- Operating Humidity: 5% ~ 85%
- Storage Humidity: 5% ~ 95%
- Dimension (WxDxH)
- 14.8 x 56.5 x 11.85 mm (compliance with SFF8432)
- Weight 19.5g
- Bail latch color: Blue
Emission (EMI) and Safety Certifications
- EMI: CE, FCC, VCCI
- Safety: UL, TUV, CDRH
| Gyártó | DLINK |
| Portok száma | Duplex LC Connector |
| Sebesség | 10Gbps |
