GIGABYTE PC BRIX, Intel Core i3 1220P 4.4GHz, 2xHDMI, MiniDisplayport, Thunderbolt, LAN, WIFI, BT, 2.5" HDD hely, 6xUSB

Dimension

52 mm x 134.2 mm x 139.1 mm (2.0" x 5.3" x 5.4")

Motherboard Size

125mm x 128.8 mm (4.9'' x 5.1")

CPU

12th Generation Intel® Core™ i3-1220P Processors, 10 Cores (2P+8E) 12 Threads, 12MB L2 Cache, Frequency 1.5GHz-4.4GHz(P Core), 28W

Memory

2 x SO-DIMM DDR4 slots, support up to 3200MHz
Max. 64GB

LAN

2.5G LAN (Intel i225V)

Wifi Card

Intel WIFI6E / BT 5.2 Module

Audio

Realtek ALC897 HD audio

Video

Intel® UHD Graphics for 12th Gen Intel® Processors, 64EU

HDMI Resolution (Max.)

1x HDMI2.1 with HDCP 2.2
Max Resolution 7680 x 4320@60Hz 1x HDMI2.0a with HDCP 2.2
Max Resolution 3840x2160@60Hz

Mini DP Resolution (Max.)

Mini DP supports : DP1.4a
Max Resolution 3840x2160@60Hz USB 4.0 Type-C DP supports : DP1.4a
Max Resolution 3840x2160@60Hz

Storage

1 x PCI-e Gen4 x 4 /SATA M.2 2280 slot
1 x 2.5" HDD/SSD, 7.0mm thick (1 x 6 Gbps SATA 3)

Expansion Slots

1 x PCIe M.2 NGFF 2230 A-E key slot occupied by the WiFi+BT card

Front I/O

1 x Power Button
1 x USB 3.2 type C (Gen2)
3 x USB 3.2 type A (Gen2)
1 x head phone jack with MIC

Rear I/O

1 x HDMI(2.1)
1 x HDMI(2.0b)
1 x mDP
1 x USB 4.0 (Support Intel Thunderbolt 4) w/ DP alt mode
2 x USB 2.0 type A
1 x RJ45
1 x DC-In
1 x Kensington lock slot

TPM

Integrate TPM module* (in selected regions /countries)

Power Supply

Input: AC 100-240V
Output: DC 19.5V / 6.92A, 135W

VESA

Mounting Bracket Included

Support OS

Windows 11 64Bit
Windows 10 64bit

Environment

Operating Temperature 0°C to 35°C
Storage Temperature -20°C to +60°C
