Leírás és Paraméterek
-
Graphics ProcessingRadeon™ RX 6950 XT
-
Core ClockBoost Clock* : up to 2324 MHz (Reference card: 2310 MHz)
Game Clock* : up to 2116 MHz (Reference card: 2100 MHz) -
Stream Processors5120
-
Process Technology7 nm
-
Memory Clock18000 MHz
-
Memory Size16 GB
-
Memory TypeGDDR6
-
Memory Bus256 bit
-
Memory Bandwidth (GB/sec)576 GB/s
-
Card BusPCI-E 4.0
-
Digital max resolution7680x4320
-
Multi-view4
-
Card sizeL=332 W=143 H=57 mm
-
PCB FormATX
-
DirectX12 Ultimate
-
OpenGL4.6
-
Recommended PSU850W
-
Power Connectors8 pin*3
-
OutputDisplayPort 1.4a *2
HDMI 2.1 *2 -
AccessoriesQuick guide
-
Note* “Boost Clock” is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads.
* “Game Clock” is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.
| Chipset gyártó | AMD |
| Chipset típusa | RX 6950XT |
| Csatlakozófelület | PCI-e x16 |
| D-Sub | - |
| DirectX | 12 |
| Displayport | 2 |
| Gyártó | GIGABYTE |
| HDMI | 2 |
| Hűtés típusa | Aktív |
| Kivitel | dobozos |
| Low profile | Nincs |
| Magórajel | 2324 |
| Memória. | 16 |
| Memória órajel | 18000 |
| Memória sávszélesség | 256 Bit |
| Memória típusa | GDDR6 |
| Mini Displayport | - |
| OpenGL | 4.6 |
| SLI/CrossFire támogatás | Van |
| USB Type-C | - |
