Leírás és Paraméterek
DISPLAY CHARACTERISTICS
| Design | Edge to edge glass, Open Frame |
| Diagonal | 55", 139cm |
| Panel | IPS LED, AG coated glass |
| Native resolution | 3840 x 2160 @60Hz (8.3 megapixel 4K UHD) |
| Aspect ratio | 16:9 |
| Panel brightness | 500 cd/m² |
| Light transmittance | 84% |
| Static contrast | 1100:1 |
| Response time (GTG) | 8ms |
| Viewing zone | horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89° |
| Colour support | 16.7mln 8bit |
| Horizontal Sync | 30 - 83kHz |
| Viewable area W x H | 1212 x 683mm, 47.7 x 26.89" |
| Bezel width (sides, top, bottom) | 29.7mm, 33.2mm, 33.2mm |
| Pixel pitch | 0.315mm |
| Bezel colour and finish | white, matte |
TOUCH
| Touch technology | projective capacitive |
| Touch points | 15 (HID, only with supported OS) |
| Touch accuracy | +- 3mm |
| Touch method | stylus, finger, glove (latex) |
| Touch interface | USB |
| Supported operating systems | All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. |
| Through-Glass | 6mm |
| Palm rejection | yes |
INTERFACES / CONNECTORS / CONTROLS
| Analog signal input | VGA x1 (max. 1920x1080 @60Hz) |
| Digital signal input | HDMI x2 (v.2.0 x1 max. 3840x2160 @60Hz, v.1.4 x1 max. 3840x2160 @30Hz) DisplayPort x1 (v.1.2 max. 3840x2160 @60Hz) |
| Audio input | Mini jack x1 |
| Monitor control input | RS-232c x1 RJ45 (LAN) x1 |
| Audio output | Mini jack x1 Speakers 2 x 8W |
| HDCP | yes |
FEATURES
| Extra | handles, touch through-glass, temperature sensor with fan control |
| Max. non-stop operating time | 24/7 |
| Anti image retention | yes |
| Glass thickness | 4mm |
| Glass hardness | 7H |
| 60950 Ball drop test | yes |
| Water and dust protection | IP54 (front) |
| Housing (bezel) | metal |
GENERAL
| OSD languages | EN, DE, FR, ES, IT, RU, NL, PL |
| Control buttons | power, menu, exit, up, down |
| User controls | picture (backlight, contrast, brightness, sharpness, H/V-position, phase, Chroma, adjust screen, colour temp., picture mode), sound (treble, bass, balance, volume, mute, speaker, audio source), screen (aspect, Touch feature, reset), settings (OSD time, OSD H/V position, language, schedule, power save, control setting, network setting, advanced, information, all reset) |
| Plug&Play | DDC2B |
MECHANICAL
| Orientation | landscape, portrait, face-up |
| VESA mounting | 600 x 400mm |
| Mini PC mount | VESA 100 x 100, NUC INTEL |
| Operation temperature range | 0°C - 40°C |
| Storage temperature range | - 20°C - 60°C |
| MTBF | 50000 hours (excluding backlight) |
ACCESSORIES INCLUDED
| Cables | power, USB, HDMI, DP |
| Guides | quick start guide, safety guide |
| Cable cover | yes |
POWER MANAGEMENT
| Power supply unit | internal |
| Power supply | AC 100 - 240V, 50/60Hz |
| Power usage | 155W typical, 1.5W stand by, 0.3W off mode |
SUSTAINABILITY
| Regulations | CE, EAC, RoHS support, ErP, WEEE, cULus, REACH, UKCA |
| Energy efficiency class (Regulation (EU) 2017/1369) | G |
| REACH SVHC | above 0.1%: Lead |
DIMENSIONS / WEIGHT
| Product dimensions W x H x D | 1271.5 x 749.4 x 68mm |
| Box dimensions W x H x D | 1400 x 930 x 245mm |
| Pallet volume | 10pcs |
| Pallet dimensions W x H x D | 1420 x 1245 x 1986mm |
| Weight (without box) | 41kg |
| Weight (with box) | 46.5kg |
| EAN code | 4948570118069 |
COMPATIBLE ACCESSORIES
| Mounts/stands/brackets | OMK4-2 |
RELATED INFORMATION
| Product series | ProLite TF3239MSC-B1AG , ProLite TF3239MSC-W1AG, ProLite TF4339MSC-B1AG, ProLite TF4939UHSC-B1AG, ProLite TF6539UHSC-B1AG |
| D-Sub | Van |
| Display Port | Van |
| Érintőképernyő (Igen/Nem) | Van |
| Fali rögzítés | 600x400mm VESA falitartó-támogatás |
| Fejhallgató kimenet | Van |
| Felbontás | 3840 x 2160 (UHD) |
| Fényerő | 500 |
| Gyártó | IIYAMA |
| Hangszóró | Van |
| HDMI | Van |
| Képátló | 55 |
| Kontrasztarány | 1100 |
| Panel típus | IPS |
| Soros port | Van |
| USB | Van |
