Leírás és Paraméterek
| Form factor | M.2 2280 |
| Interface | PCIe 4.0 x4 NVMe |
| Capacities1 | 240GB, 480GB, 960GB |
| NAND | 3D TLC |
| Sequential read/write | 240GB – 4500/400 MBs 480GB – 7000/800 MBs 960GB – 7000/1300 MBs |
| Steady-state 4k read/write2 | 240GB – 260000/18000 IOPS 480GB – 530000/32000 IOPS 960GB – 540000/47000 IOPS |
| Total bytes written (TBW)3 | 240GB – 175.2 TBW 480GB – 350.4 TBW 960GB – 700.8 TBW |
| Latency read (avg) | 240GB-960GB: 70µs |
| Latency write (avg) | 240GB – 53µs 480GB – 29µs 960GB – 20µs |
| Power loss protection (power caps) | Yes |
| Enterprise SMART tools | Reliability tracking, usage statistics, SSD life remaining, wear levelling, temperature |
| Endurance | 240GB — (0.4 DWPD/5yrs)4 480GB — (0.4 DWPD/5yrs)4 960GB — (0.4 DWPD/5yrs)4 |
| Power consumption | 240GB: Average read: 2.97W Average write: 4.02W Max read: 3.01W Max write: 4.09W 480GB: Average read: 3.22W Average write: 5.60W Max read: 3.29W Max write: 5.77W 960GB: Average read: 3.26W Average write: 7.36W Max read: 3.36W Max write: 7.80W |
| Storage temperature | -40°C ~ 85? |
| Operating temperature | 0? ~ 70? |
| Dimensions | 80mm x 22mm x 8.3mm |
| Weight | 240GB – 9g 480GB – 10g 960GB – 11g |
| Vibration non-operating | 20G peak (10-2,000Hz) |
| MTBF | 2 million hours |
| Warranty/support5 | Limited five-year warranty with free technical support |
| Csatoló | PCI-e 4.0 |
| Gyártó | KINGSTON |
| Külső/Belső | Belső |
| Méret | M.2 PCI-E |
| Szekvenciális Írás | 400 |
| Szekvenciális Olvasás | 4500 |
