Leírás és Paraméterek
| Management Type | Web Managed |
| Number of Ports | 8 |
| 10GbE SFP+ | 4 |
| 10GbE SFP+/RJ45 Combo Ports | 4
Note: The 10GbE SFP+ ports are backward compatible with 1GbE SFP; the RJ45 (copper) combo port supports up to five speeds (10G/5G/2.5G/1G/100M).
|
| Management Port | 1 x 1GbE |
| Power Supply Description | Internal Power Supply Unit |
| Max. Power Consumption | 70W |
| Input Power Type | AC |
| Input Voltage Range | 100 ? 240VAC, 50/60Hz |
| MAC Address Table | 16K |
| Total Non-Blocking Throughput | 80Gbps |
| Switching Capacity | 160Gbps |
| Management Interface | Web |
| Console | RJ45 |
| Energy Efficient Ethernet (IEEE 802.3az complaint) | Yes |
| Fan | System: 4 x 4 cm (12V) |
| Supported Standards | IEEE 802.3 Ethernet IEEE 802.3u 100BASE-T IEEE 802.3ab 1000BASE-T IEEE 802.3bz 2.5G/5GBase-T IEEE 802.3an 10G BASE-T IEEE 802.3z 1000BASE-SX/LX IEEE 802.3ae 10G Fiber IEEE 802.3x Full-Duplex Flow Control IEEE 802.1Q VLAN Tagging IEEE 802.1w RSTP IEEE 802.3ad LACP IEEE 802.1AB LLDP IEEE 802.3az Energy Efficient Ethernet (IEEE 802.1p Class of Service) |
| LED Indicators | Per Port: Speed/Link/Activity Per System: Power/Status |
| Buttons | Reset button |
| Dimensions (HxWxD) | 46,65 x 285 x 236,6 mm |
| Weight (Net) | 2.12 kg |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Relative Humidity | 5%–95% (non-condensing) |
| Certifications | FCC, CE, VCCI, BSMI, RCM, WEEE |
| Electromagnetic Compliance | CLASS A |
| Jumbo Frames | 9K |
| Warranty | 2 Years |
| Gyártó | QNAP |
| Menedzselhető | Van |
| Menedzselhetőség | Web |
| Portok száma | 8 |
| Rack-be szerelhető | Van |
| SFP port | 8 |
