Leírás és Paraméterek
| Mechanical | |
|---|---|
| Dimensions | 442.4 x 285 x 43.7 mm (17.42 x 11.22 x 1.72") |
| Weight | Without mounting brackets: 4.52 kg (9.97 lb) With mounting brackets: 4.61 kg (10.16 lb) |
| Enclosure material | SGCC steel |
| Hardware | |
| Networking interface | (48) 10/100/1,000 RJ45 ports (4) 1G SFP Ethernet ports |
| Management interface | Ethernet In-Band |
| Total non-blocking throughput | 52 Gbps |
| Switching capacity | 104 Gbps |
| Forwarding rate | 77.38 Mpps |
| Power method | 100—240V AC, 50/60 Hz, universal input |
| Power supply | AC/DC, internal, 240W |
| Supported voltage range | 100—240V AC |
| Max. power consumption | 45W (Excluding PoE output) |
| ESD/EMP protection | Air: ± 16kV, contact: ± 12kV |
| Shock and vibration | ETSI300-019-1.4 Standard |
| Operating temperature | -5 to 40° C (23 to 104° F) |
| Operating humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
| LEDs | |
| System | Status |
| Ethernet | PoE Speed/link/activity |
| SFP+ | Link/activity |
| PoE | |
| Total available PoE | 195W |
| PoE interfaces Ports 1-32 |
PoE/PoE+ (Pins 1, 2+; 3, 6-) |
| Max. PoE wattage per port by PSE PoE+ |
32W |
| Voltage range PoE mode | 44—57V |
| Voltage range PoE+ mode | 50—57V |
| Gyártó | UBIQUITI |
| Menedzselhető | Van |
| Menedzselhetőség | Web |
| Port típusa | 1Gb Réz |
| Portok száma | 48 |
| Rack-be szerelhető | Van |
| SFP port | 4 |
| Switch típus | Fixed port |
