Leírás és Paraméterek
| Mechanical | |
|---|---|
| Dimensions |
210.4 x 95 x 29 mm (8.28 x 3.74 x 1.14") |
| Weight |
610 g (1.34 lb) |
| Enclosure material |
Polycarbonate |
| Hardware | |
| Total non-blocking throughput |
9 Gbps |
| Switching capacity |
18 Gbps |
| Forwarding rate |
13.392 Mpps |
| Networking interface |
(8) 10/100/1000 MbE RJ45 ports |
| Management interface |
Ethernet in-band Bluetooth BLE |
| Power method |
External AC/DC adapter |
| Power supply |
27VDC, 4.4A power adapter (included) |
| Supported voltage range |
24 - 28VDC |
| Max. power consumption |
8W (excludes PoE output) |
| ESD/EMP protection |
Air: ± 15 kV, contact: ± 8 kV |
| Operating temperature |
-10 to 50° C (14 to 122° F) |
| Operating humidity |
5 to 95% non-condensing |
| Certifications |
CE, FCC, IC |
| PoE | |
| PoE interface |
(8) 27V passive PoE: 2-pair (pins 4, 5+/7, 8-) or 4-pair (pins 1, 2, 4, 5+/3, 6, 7, 8-) |
| Max. Passive PoE wattage per port |
30W/27VDC |
| Passive PoE voltage range |
27VDC |
| LEDs | |
| System |
Status |
| RJ45 data ports |
PoE |
| SFP data ports |
Link/activity |
| Gyártó | UBIQUITI |
| Menedzselhető | Van |
| Menedzselhetőség | Web |
| Port típusa | 1Gb Réz |
| Portok száma | 8 |
| Rack-be szerelhető | Nincs |
| SFP port | 1 |
| Switch típus | Fixed port |
