Leírás és Paraméterek
| HARDWARE FEATURES | |
|---|---|
| Interface | 1× 2.5G RJ45 Port + 1x 1G RJ45 Port |
| Button | Reset |
| Power Supply | 802.3bt PoE or 12V/2.5A DC |
| Power Consumption | 28 W (For PoE); 27 W (For DC) |
| Dimensions ( W x D x H ) | 8.7 × 8.7 × 1.3 in (220 × 220 × 32.5 mm) |
| Antenna Type | Internal Omni • 2.4 GHz: 4× 4 dBi • 5 GHz: 4× 4 dBi |
| Bluetooth | Yes |
| Mounting | Ceiling /Wall Mounting (Kits included) Junction Box mouting |
| WIRELESS FEATURES | |
|---|---|
| Coverage | 200?(2150ft2)§ |
| Wireless Client Capacity | 1,000+** |
| Concurrent Clients | 1,020+** |
| Wireless Standards | IEEE 802.11 a/b/g/n/ac/ax |
| Frequency | 2.4 GHz and 5 GHz |
| Signal Rate | • 5 GHz: 2402 Mbps • 2.4 GHz: 1148 Mbps |
| Wireless Functions | • 1024-QAM • 4× Longer OFDM Symbol • OFDMA • Multiple SSIDs (16 SSIDs, 8 on each band) • Enable/Disable Wireless Radio • Enable/Disable SSID Broadcast • Guest Network • Automatic Channel Assignment • Transmit Power Control: Adjust Transmit Power on dBm • QoS(WMM) • Seamless Roaming ? • Omada Mesh? • Beamforming • MU-MIMO • Rate Limit: Based on SSID/Client • Load Balance • Airtime Fairness • Band Steering • RADIUS Accounting • PPSK Pro • Hotspot 2.0: to be supported with subsequent software update • MAC Authentication • Reboot Schedule • Wireless Schedule • Wireless Statistics • Static IP/Dynamic IP |
| Wireless Security | • WIDS/WIPS? • Captive Portal Authentication? • Access Control • Maximum number of MAC Filter: 4000 • Wireless Isolation Between Clients • VLAN • WIDS/WIPS? • Rogue AP Detection • 802.1X Support • WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise |
| Transmission Power | • CE: < 20 dBm (2.4GHz, EIRP) < 23dBm (5 GHz, band1&band 2, EIRP) < 28 dBm (5 GHz,band 3, EIRP) • FCC: < 26 dBm (2.4 GHz) < 26 dBm (5 GHz) |
| MANAGEMENT | |
|---|---|
| Omada App | Yes |
| Centralized Management | • Omada Pro Software Controller • Omada Pro Cloud-Based Controller |
| Cloud Access | Yes. Require the use of Omada Pro Cloud-Based Controller, or Omada Pro Software Controller. |
| Email Alerts | Yes |
| LED ON/OFF Control | Yes |
| Management MAC Access Control | Yes |
| SNMP | v1, v2c, v3 |
| System Logging Local/Remote Syslog | Yes |
| SSH | Yes |
| Web-based Management | HTTP/HTTPS |
| L3 Management | Yes |
| Multi-site Management | Yes |
| Management VLAN | Yes |
| Zero-Touch Provisioning | Yes. Require the use of Omada Pro Cloud-Based Controller. |
| OTHERS | |
|---|---|
| Certification | CE, FCC, RoHS |
| Package Contents | • AP9665 • Ceiling/Wall Mounting Kits • Installation Guide |
| System Requirements | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux |
| Environment | • Operating Temperature: 0–40 ? (32–104 ?) • Storage Temperature: -40–70 ? (-40–158 ?) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing |
| Frekvencia | 2,4 GHz és 5 GHz |
| Gyártó | TP-LINK |
| Kivitel | Nincs |
| Sebesség | 2400Mbps |
| Szabvány | 802.11b, 802.11g, 802.11n, 802.11ac, 802.11ax |
