Leírás és Paraméterek
Specs
|
Type
|
Smart managed |
|---|---|
|
Number of ports
|
5 to 14 ports |
|
Layer
|
Layer 2 |
|
Main type of ports
|
1000BASE-T Gigabit Ethernet |
|
Type of uplink ports
|
1000BASE-T Gigabit Ethernet SFP |
|
PoE options
|
802.3af 802.3at |
|
Number of PoE ports
|
8 |
|
PoE power budget
|
See datasheet |
|
Fanless
|
yes
|
|
Form Factor
|
DIN rail |
|
Housing
|
Metal |
|
Jumbo frame
|
yes
|
|
Environmental
|
Free Fall: IEC60068-2-32 Shock: IEC60068-2-27 Vibration: IEC60068-2-6 |
|
<20ms link loss recovery
|
yes
|
|
MAC address
|
8K |
|
Spanning Tree Protocol
|
802.1D STP 802.1s MSTP 802.1w RSTP |
|
Link aggregation
|
802.3ad |
|
VLAN group (max static)
|
1024 256 |
|
VLAN type
|
MAC-based Port-based Protocol-based |
|
Advanced VLAN
|
Double VLAN (Q-in-Q) |
|
Number of QoS queues per port
|
8 |
|
Encryption protocol supported
|
SSH |
|
802.1X access control
|
yes
|
|
RADIUS/TACACS+ authentication
|
yes
|
|
SNMP (v1/v2c/v3)
|
yes |
|
LLDP
|
yes
|
| Gyártó | DLINK |
| Menedzselhető | Van |
| Menedzselhetőség | Web |
| Port típusa | 1Gb Fiber |
| SFP port | 4 |
| Switch típus | Fixed port |
