Leírás és Paraméterek
Specs
Compatible with
Capacity
Fiber Type
Maximum Cable Distance
Wave Length
Network Protocol and Standards
IEEE
Emissions
Safety
Physical & Environmental
Dimensions (L x W x H)
Weight
Temperature
Humidity
Power Budget
Power Voltage
Output Optical Power
- DES-1228, DES-1228P, DES-3252P, DES-3228PA, DES-1252, DGS-3612G
Capacity
- 100Mbps half-duplex (200Mbps full-duplex)
Fiber Type
- 62.5/125um Multi-mode
Maximum Cable Distance
- 2km
Wave Length
- 1310nm
Network Protocol and Standards
IEEE
- 802.3u 100BASE-FX
Emissions
- FCC Class B, CE, ICES-003, VCCI
Safety
- FDA/CDRH, TUV, UL, RoHS
Physical & Environmental
Dimensions (L x W x H)
- 0.5in x 2.28in x 0.3in
Weight
- 0.03lbs
Temperature
- Operating: 32°F to 158°F(0°C - 70°C)
- Storage: -40°F to 185° F(-40°C - 85°C)
Humidity
- Operating: 10% to 90% RH, Non-condensing
- Storage: 5% to 90% RH, Non-condensing
Power Budget
- 13dB
Power Voltage
- 3.3V
Output Optical Power
- Max.-14dBm, Min.-19dBm
| Gyártó | DLINK |
| Portok száma | 1 |
| Sebesség | 100-200Mbps |
