| ProLite T1932MSC-W1SAG | |
| DISPLAY CHARACTERISTICS | |
| Design | Edge to edge glass |
| Diagonal | 19", 48cm |
| Panel | IPS |
| Native resolution | 1280 x 1024 (1.3 megapixel) |
| Aspect ratio | 5:4 |
| Panel brightness | 250 cd/m² |
| Brightness | 215 cd/m² with touch |
| Light transmittance | 85% |
| Static contrast | 1000:1 with touch |
| Response time (GTG) | 14ms |
| Viewing zone | horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89° |
| Colour support | 16.7mln |
| Horizontal Sync | 31 - 80kHz |
| Viewable area W x H | 374.8 x 300mm |
| Pixel pitch | 0.2928mm |
| Bezel colour and finish | white, matte |
| TOUCH | |
| Touch technology | projective capacitive |
| Touch points | 10 (HID, only with supported OS) |
| Touch method | stylus, finger, glove |
| Touch interface | USB |
| Supported operating systems | All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. |
| INTERFACES / CONNECTORS / CONTROLS | |
| Analog signal input | VGA x1 |
| Digital signal input | HDMI x1 DisplayPort x1 |
| Audio input | Mini jack x1 |
| Audio output | Speakers 2 x 1W |
| HDCP | yes |
| FEATURES | |
| Water and dust protection | IP54 (front) |
| OSD key lock | yes |
| GENERAL | |
| OSD languages | EN, DE, FR, ES, IT, CN, JP |
| Control buttons | Menu, Scroll up/ Brightness, Scroll down/ Mute, Select, Power |
| User controls | Picture (contrast, brightness,, H.position, V.position, phase, clock, auto adjust), advanced (color temp., sharpness), OSD (timeout, position, H-position, V-position), option (reset, language, source select, display mode, volume, factory) |
| Convenience | Kensington-lock™ prepared |
| Plug&Play | DDC2B |
| MECHANICAL | |
| Tilt angle | 90° up; 5° down |
| VESA mounting | 100 x 100mm |
| Cable management system | yes |
| ACCESSORIES INCLUDED | |
| Cables | power, USB, HDMI, DP |
| Guides | quick start guide, safety guide |
| Cable cover | yes |
| POWER MANAGEMENT | |
| Power supply unit | internal |
| Power supply | AC 100 - 240V, 50/60Hz |
| Power usage | 20W typical, 1.5W stand by, 0.3W off mode |
| SUSTAINABILITY | |
| Regulations | CE, EAC, RoHS support, ErP, WEEE, cULus, REACH, UKCA |
| Energy efficiency class (Regulation (EU) 2017/1369) | E |
| REACH SVHC | above 0.1%: Lead |
| DIMENSIONS / WEIGHT | |
| Product dimensions W x H x D | 432 x 413.5 x 239.5mm |
| Weight (without box) | 5.4kg |
| EAN code | 4948570122219 |
| DIMENSIONS / WEIGHT | |
| Product dimensions W x H x D | 432 x 413.5 x 239.5mm |
| Weight (without box) | 5.4kg |
| EAN code | 4948570122219 |
| D-Sub | Van |
| Display Port | Van |
| Fali rögzítés | 100x100mm VESA falitartó-támogatás |
| Felbontás | 1280 x 1024 (SXGA) 5:4 |
| Fényerő | 250 |
| Gyártó | IIYAMA |
| Hangszóró | Van |
| HDMI | Van |
| Képarány | 5:4 |
| Képátló | 19 |
| Kontrasztarány | 1000 |
| Láthatósági szög | 178/178 |
| Panel típus | IPS |
| Szín | Fehér |
| Típus | Touch monitor |
| Válaszidő | 14 |
