Leírás és Paraméterek
| ProLite TF2438MSC-B1 | |
| DISPLAY CHARACTERISTICS | |
| Design | Edge to edge glass, Open Frame |
| Diagonal | 23.8", 60.5cm |
| Panel | IPS |
| Native resolution | 1920 x 1080 (2.1 megapixel Full HD) |
| Aspect ratio | 16:9 |
| Panel brightness | 600 cd/m² |
| Brightness | 525 cd/m² with touch |
| Light transmittance | 87% |
| Static contrast | 1000:1 |
| Response time (GTG) | 5ms |
| Viewing zone | horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89° |
| Colour support | 16.7mln |
| Horizontal Sync | 30 - 83kHz |
| Viewable area W x H | 527 x 296.5mm, 20.7 x 11.7" |
| Bezel width (sides, top, bottom) | 17.25mm, 20.3mm, 20.3mm |
| Pixel pitch | 0.275mm |
| Bezel colour and finish | black, matte |
| TOUCH | |
| Touch technology | bonded PCAP |
| Touch points | 10 (HID, only with supported OS) |
| Touch method | stylus, finger, glove |
| Touch interface | USB |
| Supported operating systems | All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. |
| INTERFACES / CONNECTORS / CONTROLS | |
| Digital signal input | HDMI x1 DisplayPort x1 |
| Audio output | Speakers 2 x 2W |
| HDCP | yes |
| USB HUB | x2 (USB3.2 Gen 1 (5Gbps, 5V, 900mA)) |
| FEATURES | |
| Extra | Optical bonding PCAP, metal housing, anti fingerprint coating, waterproof touch function |
| Glass thickness | 3.6mm |
| Glass hardness | 7H |
| 60950 Ball drop test | yes |
| Water and dust protection | IP1X (front) |
| Housing (bezel) | metal |
| OSD key lock | yes |
| GENERAL | |
| OSD languages | EN, DE, FR, CN, RU, JP, NL, PL |
| Control buttons | Menu, Scroll up/ Eco, Scroll down/ Volume, Enter/ Input select, Power |
| User controls | Picture adjust (brightness, contrast, i-Style color, adv. contrast, ECO mode, OD, X-Res), color settings (gamma, RGB range, color. temp.), image settings (video mode adjust, blue light reducer, sharp & soft), OSD (H. pos., V. pos., time, background, rotate, language, display information), extra (reset, DDC/CI, signal select, volume, mute, led, opening logo, touch switch) |
| Blue light reducer | yes |
| Plug&Play | DDC2B |
| MECHANICAL | |
| Orientation | landscape, portrait, face-up |
| Fanless design | yes |
| VESA mounting | 100 x 100mm |
| ACCESSORIES INCLUDED | |
| Cables | power, USB, HDMI |
| Guides | quick start guide, safety guide |
| Cable cover | yes |
| POWER MANAGEMENT | |
| Power supply unit | internal |
| Power supply | AC 100 - 240V, 50/60Hz |
| Power usage | 22W typical, 1.5W stand by, 0.3W off mode |
| SUSTAINABILITY | |
| Regulations | CE, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH, UKCA, cTUVus |
| Energy efficiency class (Regulation (EU) 2017/1369) | E |
| Energy efficiency class | E |
| REACH SVHC | above 0.1%: Lead |
| DIMENSIONS / WEIGHT | |
| Product dimensions W x H x D | 561.5 x 337 x 47.5mm |
| Display Port | Van |
| Fali rögzítés | 100x100mm VESA falitartó-támogatás |
| Felbontás | 1920 x 1080 (FHD1080) 16:9 |
| Fényerő | 600 |
| Gyártó | IIYAMA |
| Hangszóró | Van |
| HDMI | Van |
| Képarány | 16:9 |
| Képátló | 23.8 |
| Kontrasztarány | 1000 |
| Láthatósági szög | 178/178 |
| Panel típus | IPS |
| Szín | Fekete |
| Típus | Touch monitor |
| USB | Van |
| Válaszidő | 5 |
