Leírás és Paraméterek
Connector(s)
External Ports
3 - USB Type-A (9 pin, 5 Gbps)
1 - RJ-45
1 - USB Micro-B (5 pin) (Power)
Host Connectors
1 - USB Type-A (9 pin, 5 Gbps)
Environmental
Operating Temperature
0°C to 70°C (32°F to 158°F)
Storage Temperature
-40°C to 80°C (-40°F to 176°F)
Humidity
0% to 95 % at 25 ?
Hardware
USB-C Device Port(s)
No
USB-C Host Connection
Yes
Fast-Charge Port(s)
No
Ports
3
Interface
USB 3.2 Gen 1 (5Gbps)
RJ45 (Gigabit Ethernet)
Bus Type
USB 3.2 Gen 1 (5Gbps)
Industry Standards
IEEE 802.3u, IEEE 802.3ab
IEEE 802.3az Energy-Efficient Ethernet, IEEE 802.3x Flow Control, 802.1q VLAN Tagging, 802.1p Layer 2 Priority Encoding
USB 3.0 - Backward compatible with USB 2.0 and 1.1
Chipset ID
VIA/VLI - VL817
ASIX - AX88179A
Indicators
LED Indicators
1 - Network Link LED - Green
1 - Network Activity LED - Amber
Packaging Information
Package Length
6.7 in [17.0 cm]
Package Width
5.6 in [14.2 cm]
Package Height
1.2 in [3.0 cm]
Shipping (Package) Weight
4.9 oz [138.0 g]
Package Quantity
1
Performance
Maximum Data Transfer Rate
5 Gbps (USB 3.2 Gen 1)
2 Gbps (Ethernet; Full-Duplex)
Type and Rate
USB 3.2 Gen 1 - 5 Gbit/s
UASP Support
Yes
Flow Control
Full duplex flow control
Compatible Networks
10/100/1000 Mbps
Auto MDIX
Yes
Full Duplex Support
Yes
Jumbo Frame Support
9K max.
Physical Characteristics
Color
Space Gray
Form Factor
Compact
Product Length
16.5 in [42.0 cm]
Product Width
2.1 in [5.4 cm]
Product Height
0.6 in [1.6 cm]
Weight of Product
2.9 oz [82.0 g]
Form Factor
Attached Cable
Material
Plastic
Cable Length
11.8 in [30 cm]
Power
Power Source
Bus Powered
Software
OS Compatibility
Windows® 7, 8, 8.1, 10, 11
macOS 10.11, 10.12, 10.13, 10.14, 10.15, 11.0, 12.0, 13.0, 14.0 VLAN tagging is currently not supported in macOS
Linux Kernel 4.11.x (and up) - LTS versions only
ChromeOS
iPadOS
Android
Special Notes / Requirements
Note
USB 3.2 Gen 1 (5Gbps) is also known as USB 3.1 Gen 1 (5Gbps) and USB 3.0 (5Gbps).
Wake-on-LAN (WoL) functionality can be disabled by the host computer, if the host computer USB controller enters power save mode. It's recommended that USB power save modes be disabled within your operating system, if the WoL functionality is required for your application.
What's in the Box
Included in Package
1 - USB-C Hub
