Leírás és Paraméterek
| KAMERA | |
|---|---|
| Képérzékelő | 1/3” Progressive Scan CMOS |
| Min. szükséges megvilágítás | 0 lux with IR/white Light |
| Day/Night Mechanism | IR Cut Filter |
| Optika | Fixed focal lens (2.8 mm / 4 mm / 6 mm) |
| Aperture | 4 mm: F1.6 |
| Lens Mount | M12 |
| Látószög | (4mm) Horizontal FOV: 79°, Vertical FOV: 43°, Diagonal FOV: 93° |
| Digitális nagyítás | Yes |
| IR Working Distance | 30m |
| Illumination Distance | 30 m |
| Forgatási/döntési szög | Pan: 0° to 350°, Tilt: 0° to 120° |
| Weatherproof Rating | IP66 |
| Digital Noise Reduction | 3D DNR |
| WDR | DWDR |
| HÁLÓZAT | |
|---|---|
| Biztonság | Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication |
| Szabvány | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
| API | ONVIF |
| Simultaneous Live View | 3 Main Streams & 3 Sub-Streams |
| FIZIKAI KEZELŐFELÜLET | |
|---|---|
| Hálózati csatlakozás | 1 RJ45 10/100M Self-Adaptive Ethernet Port |
| Audio Input | Built-in Microphone |
| Audio Output | Built-in Speaker |
| Gomb | Reset Button |
| Slot | Micro SD card |
| On-board Storage | Built-In Memory Card Slot, Support MicroSD Card, Up to 256 GB |
| ÁLTALÁNOS | |
|---|---|
| Csomagolás tartalma | VIGI Network Camera Quick Start Guide Waterproof Cable Attachments Mounting Accessories (Screws, Drywall Anchors, Hex Key) |
| Operating Temperature | -30–60 °C |
| Méret (Ma x Sz x Mé) | 120 × 172 × 198 mm |
| Material | Plastic |
| General Features | Two Streams, Mirror, Privacy Masks, Password Reset via E-mail, HTTP Listening |
| Power Supply | 12V DC ± 5%, 5.5mm Coaxial Power Plug PoE (802.3af/at, class 4) |
| Power Consumption | 12V DC: Max 14W PoE: Class 4 |
| Certifications | CE, RCM, BSMI, VCCI, RoHS, NTRA, KC |
| VIDEÓ/KÉP | |
|---|---|
| Videó tömörítés | Main stream: H.265+/H.265/H.264+//H.264 Sub-Stream: H.265/H.264 |
| Kép frissítés (frame) és felbontás | Main Stream Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps Resolution: 2560x1440, 2304x1296, 2048x1280, 1920x1080 Sub-Stream Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps Resolution: 640x480, 352x288, 320x240 |
| Videótovábbítás | Main Stream Sub-Stream |
| Képbeállítás | Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance Adjustable by Client Software |
| Image Enhancement | BLC/3D DNR/Prevent Overexposure to Infrared Light |
| Video Bit Rate | Main Stream: 256 Kbps to 4 Mbps Sub-Stream: 64 Kbps to 512 Kbps |
| SMART FEATURE-SET | |
|---|---|
| Smart Event | Area Intrusion Detection, Line-Crossing Detection, Human Detection |
| Basic Event | Motion Detection, Camera Tampering Detection, Exception ( illegal login) |
| Linkage Method | Trigger Notification: ONVIF, HTTPS |
| Region of Interest | 1 Region |
| Csatlakozók | LAN |
| Gyártó | TP-LINK |
| Kivitel | Van |
| Színes/FF | Színes |
